Steam Hose 210°C
steel cord hose for saturated steam at a maximum working pressure 18 bar (261psi), used in the chemical industry, petrochemical and industrial applications in general. Not recommended for steam cleaner. The hose can be used for peaks of superheated steam at 230°C and at 18 bar.
Tube: black, smooth, IIR rubber, resistant to saturated steam.
Reinforcement: inserts of steel wire.
Cover: red, pin pricked, smooth (wrapped finish), EPDM rubber with excellent resistance to high temperatures, weathering, abrasion, and ageing.
Temperature: from -40°C (-40°F) to +210°C (+410°F).
Inside Diameter |
Outside Diameter |
Working Pressure |
Burst Pressure |
Nominal Weight |
|||||
Mm inch |
Mm inch |
Bar psi |
Bar psi |
kg/m lbs/ft |
|||||
13 |
1/2 |
25 |
0,99 |
18 |
270 |
180 |
2700 |
0,51 |
0,34 |
19 |
3/4 |
31 |
1,22 |
18 |
270 |
180 |
2700 |
0,67 |
0,45 |
25 |
1 |
37 |
1,46 |
18 |
270 |
180 |
2700 |
0,90 |
0,61 |
51 |
2 |
65 |
2,56 |
18 |
270 |
180 |
2700 |
2,15 |
1,44 |
13 |
1/2 |
25 |
0,99 |
18 |
270 |
180 |
2700 |
0,51 |
0,34 |
19 |
3/4 |
31 |
1,22 |
18 |
270 |
180 |
2700 |
0,67 |
0,45 |
25 |
1 |
37 |
1,46 |
18 |
270 |
180 |
2700 |
0,90 |
0,61 |
