EPDM Chemical Suction Hose
EPDM Chemical Suction Hose
Flexible hose for suction and delivery of chemical products, with EPDM rubber and in accordance with EN 12115.
Tube: black, smooth, EPDM rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), EPDM rubber, resistant to chemical products, abrasion, weathering and ozone.
Temperature: -40°C(- 40°F) +100°C(+212°F) depending on medium.
|
Inside Diameter |
Outside Diameter |
Working Pressure |
Burst Pressure |
Nominal Weight |
Banding Radius |
Vacuum |
||||||
|
Mm inch |
Mm inch |
Bar psi |
Bar psi |
kg/m lbs/ft |
Mm |
Inch |
bar |
|||||
|
19 |
3/4 |
31,5 |
1,24 |
16 |
240 |
64 |
960 |
0,66 |
0,44 |
115 |
4,5 |
0,9 |
|
25 |
1 |
38 |
1,50 |
16 |
240 |
64 |
960 |
0,88 |
0,59 |
150 |
5,9 |
0,9 |
|
32 |
1-1/4 |
45 |
1,77 |
16 |
240 |
64 |
960 |
1,07 |
0,72 |
175 |
6,9 |
0,9 |
|
38 |
1-1/2 |
52 |
2,05 |
16 |
240 |
64 |
960 |
1,37 |
0,92 |
225 |
8,9 |
0,9 |
|
51 |
2 |
66 |
2,60 |
16 |
240 |
64 |
960 |
1,88 |
1,26 |
275 |
10,8 |
0,9 |
|
63,5 |
2-1/2 |
78 |
3,07 |
16 |
240 |
64 |
960 |
2,42 |
1,63 |
340 |
13,4 |
0,9 |
|
75 |
2-61/64 |
90,5 |
3,57 |
16 |
240 |
64 |
960 |
2,94 |
1,97 |
350 |
13,8 |
0,8 |
|
102 |
4 |
118 |
4,65 |
16 |
240 |
64 |
960 |
4,24 |
2,85 |
450 |
17,7 |
0,8 |
